Fike Input/Output Relay Module (802-0006)

The Fike 802-0006 Twinflex I/O Module is a compact and reliable interface designed for use with the Fike Twinflex Pro and Twinflex V3 fire alarm systems. It features two single-pole changeover relays (SPCO), capable of switching 2A at 30V DC or 250V AC with a 3A surge capacity. The module includes a monitored input with built-in end-of-line supervision, ensuring secure and fault-monitored connections.

Configuration is easy using onboard DIP switches, allowing you to set alarm modes, reset behavior, and EOL types. It includes LED indicators for clear visual status of input and output states. The device is designed to fit a standard UK double-gang back box (146 × 87 × 41 mm) and is suitable for indoor use with an IP30 rating. It operates within a temperature range of –10°C to +45°C and consumes minimal power, with a standby current of just 0.207mA.

The I/O module is ideal for integrating external systems such as door releases, ventilation controls, plant shutdown mechanisms, or auxiliary alarms. It supports fire-rated screened 2-core cabling, with a maximum input cable length of 3 meters, and complies with EN54-18 standards for fire alarm device interfaces.
